AIMS Power Monocrystalline 190 Watt Solar Panel Solar Panels AIMS Power

AIMS Power Monocrystalline 190 Watt Solar Panel

  • Vendor
    AIMS Power
    Sale price
    $199.00
    Regular price
    $229.00 You save 13%
    Unit price
    per
    5% off and Free Shipping
    Coupon Code: THANKS | Ends:

    Availability:

    Estimated Arrival: Between May 19 and May 23. *ETA to the USA Only

    Shipping & Returns: Free Shipping. All The Time.

    Why Buy From Solar Power Lifestyle

    The 190 Watt Monocrystalline Solar Panel from AIMS Power is a versatile performer constructed with tempered glass and a stronger surface to protect from harsh weather conditions. The solar cells used in this panel provide high light transmission and the textured glass allows for a more efficient panel. The panel also includes a bypass diode that minimizes the power drop caused by shade. Easy to install using the pre-drilled holes on the aluminum outer frame. Perfect for home, vehicle and RV installations and industrial applications.

    Features:

    •     Monocrystalline efficient solar harvesting
    •     Strong surface for harsh environment
    •     Panels capable of 0 to +3 Watts over rated capacity
    •     Pre-drilled aluminum frame
    •     Temperated glass
    •     25 Year limited warranty

    Specs:

    • Maximum Power (Watts): 190 watts
    • (Vmp): 18.7 volts  operating voltage
    • (Imp): 10.16 amps operating current
    • (Voc): 22.44 volts open circuit voltage
    • (Isc): 10.92 amps
    • Solar Cell: 156mm x 52mm
    • Number of Cells (pcs): 12*3 = 36
    • Front Glass Thickness (mm): 3.2 mm
    • Temperature Coefficients of Isc (%) °C: -0.048
    • Temperature Coefficients of Voc (%) °C: -0.29
    • Temperature Coefficients of Pm (%) °C: -0.37
    • Temperature Range: -40°C to +80°C
    • Tolerance Wattage: 0-3 watts
    • Surface Maximum Load Capacity: 6000Pa snow and 3600Pa wind
    • Allowable Hail Load: 45mm at 30.7m/s
    • Bypass Diode Rating (A): 10
    • Cell Efficiency (%): 21.69%
    • Module Efficiency (%): 19.16%
    • Warranty: 91.2% of 12 years, 80.6% of 25 years
    • Weight Per Panel (lbs): 26.5 lbs
    • Dimensions (inches): 58.25 x 26.5 x 1.37
