Renogy 400 Watt 12 Volt Solar RV Kit

  • Vendor
    Renogy
    Sale price
    $739.99
    Regular price
    $739.99
    Unit price
    per
    Join our exclusive email community for access to members only discount coupons. | Ends:
    Shipping calculated at checkout.

    Availability:

    Shipping & Returns: Free Shipping. All The Time.

    Why Buy From Solar Power Lifestyle

    Renogy 400 Watt 12 Volt Solar RV Kit

    Adding a solar power system to an RV can create added convenience and savings. Solar panels produce energy from the sunlight, an abundant and renewable energy source. Adding solar panels can help you dock and park your recreational vehicle without a power hookup, potentially resulting in cost savings and greater freedom. Unlike traditional gas generators, Renogy 400 Watt 12 Volt Solar RV Kit silently recharges your batteries so you can enjoy the great outdoors without the extra noise. Solar panels also allow you to run limited low watt electrical equipment without a power hookup.

    Renogy RV Kits are carefully arranged to meet your RV needs. This kit includes four 100W 12V Monocrystalline Solar Panels, one Adventurer 30A PWM Charge Controller, one 30ft 10AWG Solar Adaptor Kit, one 16ft 10AWG Tray Cable, three pairs of Branch Connectors, a BT-1 Bluetooth Moduleand one Renogy Cable Entry Housing.

    The Adventurer 30A PWM Charge Controller is specifically designed for RV applications as it allows for aesthetically clean flush mounting on walls and is negative-grounded for battery compatibility. It also features an LCD screen for displaying system operation information and data and allows for full control of parameter settings. The control is embedded with self-diagnostics and electronic protection functions that prevent damage from installation mistakes or system faults.

    Newly added BT-1 Bluetooth Module enables user to pair the charge controller with our smartphone app DC Home. The APP allows you to view system performance in real time and make parameter changes right from your smartphone!

    KEY FEATURES

    Efficient

    • High solar cell efficiency : Monocrystalline 21%
    • Bypass diodes minimize power drop caused by shade and ensure excellent performance in low-light environments

    Reliable

    • EL tested solar modules; no hot-spot heating guaranteed
    • Corrosion-resistant aluminum frame for extended outdoor use, allowing the panels to last for decades
    • TPT back sheet ensures smooth performance over a long period of time
    • IP65 rated junction box provides complete protection against environmental particles and low pressure water jets

    Intuitive

    • Sealed, Gel and Flooded charging algorithim ready 4-Stage battery charging process for a rapid, efficient, and safe battery charging
    • Remote monitoring and control via Bluetooth

    Safe

    • The Renogy Adventurer is equipped with multiple electronic protections: reverse current, overcharging, short-circuit and reversed polarity
    • Pre-drilled holes on the back of the panel allow for fast and secure mounting
    RENOGY 100W MONOCRYSTALLINE SOLAR PANEL RENOGY BT-1 BLUETOOTH MODULE
    Maximum Power: 100W Input Voltage: 5V-12V
    Maximum System Voltage:600V DC Communication Range: ≤15m
    Open-Circuit Voltage (Voc): 21.6V Dimensions: 2.6 X 2.01 X 0.61 In
    Short-Circuit Current (Isc): 6.24A Weight: 120 g (4.2oz)
    Optimum Operating Voltage (Vmp): 17.9V
    Optimum Operating Current (Imp): 5.72A
    Weight: 14.3lbs
    Dimensions: 42.2 X 19.6 X 1.38 inches
    RENOGY 16FT 10AWG TRAY CABLES (A PAIR) RENOGY SOLAR Y BRANCH CONNECTORS
    Length: 16ft Withstanding Voltage: 1000V DC(TUV), 600V(UL)
    AWG: 10 Protection Degree: IP67, mated
    Rating Voltage: 600V Wiring Size Range: 10, 12, 14 AWG
    Temperature: -40°F to +185°F Temperature: -40°F to +194°F
    RENOGY ADVENTURER - 30A PWM NEGATIVE-GROUND CHARGE CONTROLLER WITH LCD DISPLAY RENOGY CABLE ENTRY HOUSING
    Nominal Voltage: 12 VDC Material: UV-resistant ABS Plastic
    Rated Charge Current: 30A Weight (each component): 7.9 oz.
    Max. PV Input Voltage: 25 VDC Recommended Adhesive: Sikaflex 252 or alike
    Max. PV Input Power: 400W (12V) Dimensions (l x w x h): 4.7 x 3.9 x 2.0 in
      Cable Gland Diameter Range: 6mm – 12mm
    MOUNTING Z BRACKETS (SET) RENOGY 30FT 10AWG SOLAR ADAPTOR KIT (A PAIR)
    Eight Long Cap Bolts and Four Short Bolts Length: 30ft
    Four Spring Washers and Four Washers AWG: 10
    Four Z Shape Solar Panel Brackets Rating Voltage: 600/1000V
    Four Nuts Temperature: -40°F to +185°F


    WARRANTY INFORMATION

    Panels

    25-year power output warranty: 5 year/95% efficiency rate, 10 year/90% efficiency rate, 25-year/80% efficiency rate

    5-year material and workmanship warranty

    Accessories 1-year material warranty
